RY-330/450 Stacked Flexographic Presses

Home > Products > Presses

Product Introduction

Print this page Send email Product Inquiry

Performance and characteristics

■ The main motor adopts imported inverter to govern a stepples speed adjustment.
■ Feeding and rewinding are controlled through magnetic particle brake and clutch (Japanese Mitsubishi auto tension controller).
■ Unwinder system is controlled by edge guide sensor.
■ Adopt ceramic anliox roller which offers durability, wear resistance and corrosion resistance. also is more efficient on production by reducing the times of changing rollers.
■ The printing units are all equipped with a group of infrared dryers respectively .
■ Each IR dryer device of printing unit is interchangeable to UV dryer.
■ Unwinder and rewinder adopt air core holder.
■ The printing unit can register in 360 degrees. Each printing unit can be independently geared and loosen to have rest of units continue to printing.
■ The roll feeding, printing, UV vanish, auto infrared drying, laminating and rewinding can be processed in one pass.
■ The inking roller will be automatically off impression when press stop and rotate at lower speed in order to keep the ink from being drying.
■ RY-330/450 is characterized by wide application, fast printing speed, high economic efficiency and ink pollution. It is an ideal printing machine for the business form, tag and high end pressure sensitive label.

Technical Specification

Model	RY-330	RY-450
Max. Web Width	320mm	450mm
Max. Printing Width	310mm	440mm
Printing Repeat	180mm-380mm/min	180mm-380mm/min
Color	2～6	2～6
Thickness of Substrate	0.1～0.3mm	0.1～0.3mm
Machine Speed	10m-80m/min	10m-80m/min
Max. Unwind Diameter	600mm	600mm
Max. Rewind Diameter	550mm	550mm
Main Motor Capacity	2.2kw	2.2kw
Main Power	380V/AC 3 phase 50HZ	380V/AC 3 phase 50HZ
Overall Dimension(LxWxH)	3000x1500x3000mm	3000x1700x 3000mm
Machine Weight	2000kg	2300kg

*lts overall dimension and manufacturing Process are subject to change without further notice.
